Scissor Lift Tables are high-quality electronic hydraulic scissor lifts with loading capacities from 400KG to 4,000KG, and lifting heights up to 4210mm.We also accept customized platform size and lifting height.It can be installed both on the ground and in the pit.
If you need it, please click below to get a free quote
| Model | Load Capacity (kg) | Self Height (mm) | Max Platform Height (mm) | Platform Size(mm) | Lifting time (S) | Net weight (kg) |
| HW1001 | 1000 | 205 | 990 | 1300×820 | 20~25 | 160 |
| HW1002 | 1000 | 205 | 990 | 1600×1000 | 20~25 | 186 |
| HW1003 | 1000 | 240 | 1300 | 1700×850 | 30~35 | 200 |
| HW1004 | 1000 | 240 | 1300 | 1700×1000 | 30~35 | 210 |
| HW1005 | 1000 | 240 | 1300 | 2000×850 | 30~35 | 212 |
| HW1006 | 1000 | 240 | 1300 | 2000×1000 | 30~35 | 223 |
| HW1007 | 1000 | 240 | 1300 | 1700×1500 | 30~35 | 365 |
| HW1008 | 1000 | 240 | 1300 | 2000×1700 | 30~35 | 430 |
| HW2001 | 2000 | 230 | 1000 | 1300×850 | 20~25 | 235 |
| HW2002 | 2000 | 230 | 1000 | 1600×1000 | 20~25 | 268 |
| HW2003 | 2000 | 250 | 1300 | 1700×850 | 25~35 | 289 |
| HW2004 | 2000 | 250 | 1300 | 1700×1000 | 25~35 | 300 |
| HW2005 | 2000 | 250 | 1300 | 2000×850 | 25~35 | 300 |
| HW2006 | 2000 | 250 | 1300 | 2000×1000 | 25~35 | 315 |
| HW2007 | 2000 | 250 | 1400 | 1700×1500 | 25~35 | 415 |
| HW2008 | 2000 | 250 | 1400 | 2000×1800 | 25~35 | 500 |
| HW4001 | 4000 | 240 | 1050 | 1700×1200 | 30~40 | 375 |
| HW4002 | 4000 | 240 | 1050 | 2000×1200 | 30~40 | 405 |
| HW4003 | 4000 | 300 | 1400 | 2000×1000 | 35~40 | 470 |
| HW4004 | 4000 | 300 | 1400 | 2000×1200 | 35~40 | 490 |
| HW4005 | 4000 | 300 | 1400 | 2200×1000 | 35~40 | 480 |
| HW4006 | 4000 | 300 | 1400 | 2200×1200 | 35~40 | 505 |
| HW4007 | 4000 | 350 | 1300 | 1700×1500 | 35~40 | 570 |
| HW4008 | 4000 | 350 | 1300 | 2200×1800 | 35~40 | 655 |
| HD1000 | 1000 | 305 | 1780 | 1300X820 | 35-45 | 210 |
| HD2000 | 2000 | 360 | 1780 | 1300X850 | 35-45 | 295 |
| HD4000 | 4000 | 400 | 2050 | 1700X1200 | 55-65 | 520 |
| HT1000 | 1000 | 470 | 3000 | 1700×1000 | 35-45 | 450 |
| HT2000 | 2000 | 560 | 3000 | 1700×1000 | 50-60 | 750 |
| HF400 | 400 | 600 | 4140 | 1700×1000 | 30-40 | 800 |
| HF800 | 800 | 706 | 4210 | 1700×1000 | 70-80 | 858 |
| HF2000 | 2000 | 850 | 4200 | 2500×1500 | 80-90 | 980 |
| HW501 | 500 | 200 | 1000 | 1200*600 | 20~25 | 120 |
| HW502 | 500 | 200 | 1000 | 1200*800 | 20~25 | 130 |
| HW500L | 500 | 200 | 1000 | 2000*800 | 20~25 | 240 |
| HD2000L | 2000 | 205 | 1000 | 2500*820 | 20~25 | 300 |
| HD4000L | 4000 | 230 | 1000 | 2500*850 | 20~25 | 320 |
| HD8000L | 8000 | 240 | 1050 | 3000*1200 | 20~25 | 370 |
| HW1001Z | 1000 | 180 | 770 | 610*916 | 15~20 | 115 |
| HW0501Z | 500 | 180 | 950 | 610*916 | 17~22 | 160 |
| HW100I | 1000 | 190 | 1010 | 1300*800 | 20~25 | 160 |
| HW200I | 2000 | 190 | 1010 | 1300*800 | 20~25 | 235 |
| HW300I | 3000 | 220 | 1010 | 1300*800 | 20~25 | 350 |
