Spider cranes, also known as mini cranes or compact cranes, are versatile pieces of equipment that have a wide range of applications in the construction industry. These innovative machines are capable of lifting and moving heavy loads with great precision and control, making them ideal for use in restricted or confined spaces where larger cranes cannot operate.
If you need it, please click below to get a free quote
| Model | CL1.5 | CL3.0 | CL5.0 | CL8.0 | CL10.0 | CL12.0 | CL14.0 | CL16.0 | |
| Specifications | 1.5ton | 3ton | 5ton | 8ton | 10ton | 12ton | 14ton | 16ton | |
| Maximum Operating Radius | 6m | 10.5m | 15m | 18m | 18m | 19m | 23m | 23m | |
| Maximum Ground Lift | 6.5m | 10.8m | 17m | 21m | 21m | 21m | 25m | 25m | |
| Winch Device | Hook Lifting Speed | 0-8m/min(4 ropes) | 12m/min (4 ropes) | 11m/min (4 ropes) | 10m/min (4 ropes) | ||||
| Steel Rope | Φ8mm×45m | Φ12mm×80m | Φ12mm×100m | Φ12mm×120m | Φ12mm×140m | ||||
| Telescopic Device | Boom Form | 2m*4-section | 2.4m*6-section | 4m*5-section | 5m*5-section | 5m*5-section | 5m*5-section | 6m*5-section | 6m*5-section |
| Boom Length/Time | 6.5m/20s | 3.1m-9.2m/20s | 4.5m-17m/54s | 5.5m-21m/54s | 12.3m/58s | 12.3m/60s | 12.3m/40s | 12.3m/40sec | |
| Luffing Device | Boom Angle/Speed | 0-78°/13s | 0-78°/13s | 0-78°/13s | 0-78°/13s | 0-78°/15s | 0-78°/17s | 0-78°/17s | 0-78°/17s |
| Gyroscope | Rotation Angle | 0-360° (Continuous) | |||||||
| Rotation Speed | 60s | 60s | 38s | 38s | 40s | 42s | 42s | 42s | |
| Outrigger | Movement Form | Manual screw out+oil pressure automatic support (two legs) | Manual screw out+hydraulic telescopic+automatic support | ||||||
| Running Gear | Walking Mode | Hydraulic motor drive | |||||||
| Walking Speed | 0-2.5km/h | ||||||||
| Gradeability | 25° (36%) | ||||||||
| Electrical Machinery | Voltage | AC 380V (Customized according to customer needs) | |||||||
| Engine | Manufacturer | Honda | Changchai | Yunnei | Yunnei | Yunnei | Yunnei | Yuchai | Yuchai |
| Start Mode | Electric start | ||||||||
| Fuel/Volume | Gasoline/4L | Diesel Oil/8L | Diesel Oil/45L | ||||||
| Operating System | Boom/Leg | Manual operation, manual walking (optional remote control) | |||||||
| Power | AC+Gasoline | AC+Diesel | AC+Diesel | AC+Diesel | AC+Diesel | AC+Diesel | AC+Diesel | AC+Diesel | |
| Overall Size (L*W*H) | 2.5*0.6*1.5m | 3.5*0.8*1.85m | 4.7*1.5*2.25m | 6.15*1.6*2.25m | 6.15*1.8*2.3m | 6.15*1.86*2.48m | 6.6*2*2.48m | 6.6*2*2.48m | |
| Net Weight | 1300kg | 2700kg | 6100kg | 8700kg | 10500kg | 12500kg | 14500kg | 16500kg | |
